Brief Description an Applications:
|
AWS - Classification
|
EN - Classification
|
|
|
Z – 7
|
A5.1 E 7016
|
2560-A: E 46 3 B 11 H10
|
|
|
Basic coated electrode for high quality joining of general construction steels, Very good X-ray properties. Suitable for root pass welding in narrow joints. Good impact toughness at low temperatures.
|
|
|
|
|
Z - DIALOGUE
|
A5.1 E 7016
|
2560-A: E 42 3 B 12 H10
|
|
|
Double coated basic electrode.
Suitable for repair and maintenance work.
Excellent for root pass and all positional welding.
High impact toughness at low temperatures.
|
|
|
|
|
Z - 2
|
A5.1 E 7018
|
2560-A: E 42 3 B 32 H10
|
|
|
Basic coated all position welding electrode.
Good toughness at low temperatures, suitable for welding general structural steels.
|
|
|
|
|
Z - 4
|
A5.1 E 7018
|
2560-A: E 46 3 B 32 H5
|
|
|
Basic coated low hydrogen electrode with high ductility.
Suitable for welding general construction steels. Very good bead appearance and good impact toughness at -30ºC.
|
|
|
|
|
Z – 4 AC
|
A5.1 E 7018
|
2560-A: E 46 3 B 32 H5
|
|
|
Basic coated low hydrogen electrode with high ductility.
Suitable for welding general construction steels. Very good bead appearance and good impact toughness at -30ºC.
Preferably welded on AC
|
|
|
|
|
Z - 55
|
A5.1 E 7018-1
|
2560-A: E 46 5B 32 H5
|
|
|
Low hydrogen basic electrode designed for welding in all positions.
Excellent strength and high toughness down to -46ºC.
Suitable for welding medium and high strength steels.
It can be used in as welded conditions or after heat treatment.
|
|
|
|
|
Z - 42
|
A5.1 E 7028
|
2560-A: E 42 3 RB 53 H5
|
|
|
High efficiency basic electrode (160% metal recovery).
Fast deposition rates and high productivity.
Ideal for steel construction, bridges, ship building, containers and storage tank welding with high porosity resistance.
|
|
|
|
|
Z - 47
|
A5.1 E 7048
|
2560-A: E 42 3 B 35 H10
|
|
|
Vertical down welding basic electrode, recommended for welding in shipbuilding construction. With this electrode the welding is with very little slag and spatter loss. Suitable for high welding speed.
|
|
|
|
|
Z - 23
|
A5.1 E 7018-A1
|
1599: E Mo B 32 H5
|
|
|
Basic coated electrode for welding creep resistant Mo containing low-alloy steels
Withstands service temperatures up to 525ºC
|
|
|
|
|
Z – 31S
|
A5.5 E 8018-B2
|
1599: E CrMo1 B 32 H5
|
|
|
Basic coated electrode for welding creep resisting steels containing 1% Cr and 0.5% Mo, Service temperatures of maximum 550ºC.
|
|
|
|
|
Z - 32
|
A5.5 E 8018-C1
|
2560-A: E 46 6 2Ni B 42 H5
|
|
|
Basic coated electrode for welding low alloy structures subjected to service down to (-)60ºC Good corrosion resistance to choleric and sulphuric acid.
|
|
|
|
|
Z - 34
|
A5.5 E 8018-C3
|
2560-A : E 46 5 1Ni B 32 H5
|
|
|
Low hydrogen basic coated electrode Suitable for welding of low alloyed, fined grained and high tensile strength steels.
|
|
|
|
|
Z - 3
|
A5.5 E 8018-G
|
2560-A: E 50 2 B 32 H5
|
|
|
Basic coated low hydrogen electrode Suitable for maintenance repairing of agricultural equipment. The electrode produces crack free and tough welded joints.
|
|
|
|
|
Z – 3P
|
A5.5 E 8018-G
|
2560-A: E 503Mo B 42 H5
|
|
|
Low hydrogen welding electrode with basic coating. Designed for all position welding except vertical down. Especially recommended for filler and cover layers of pipeline.
|
|
|
|
|
Z - 8
|
A5.5 E 8018-G
|
2560-A: E 50 6 Mn 1 Ni B 32 H5
|
|
|
Basic coated electrode with maximum 1% Ni Excellent impact toughness at very low temperatures.
|
|
|
|
|
Z- 33
|
A5.5 E 8018-G
|
2560-A: E 50 5 B 32 H5
|
|
|
Basic coated low hydrogen electrode Designed for all position welding suited for welding high strength, fine grained structural steels and high impact toughness at (-)46ºC.
|
|
|
|
|
Z – 3W
|
A5.5 E 8018-W
|
2560-A: E50 2 B 32 H5
|
|
|
Basic coated electrode for welding thick structural “weathering” steels of similar composition resistant to atmospheric corrosion with high mechanical properties.
|
|
|
|
|
Z – 41S
|
A5.5 E 9018-B3
|
1599: E CrMo2 B 32 H5
|
|
|
Basic coated electrode for welding creep resisting steels containing 2% Cr and 1% Mo. Service temperatures of maximum 600ºC.
|
|
|
|
|
Z - 46
|
A5.5 E 9018-D1
|
2560-A: E 50 5 MnMo B 32 H5
|
|
|
Basic coated electrode with extremely low diffusible hydrogen content suited for welding high tensile structural steels and welding under very low temperature.
|
|
|
|
|
Z – 40S
|
A5.5 E 9018-G
|
2560-A: E 50 A 32 H5
|
|
|
Basic coated electrode for welding steels such as 4130 and 8630 subjected to heat treating. Welded joints are crack free and tough.
|
|
|
|
|
Z- X70
|
A5.5 E 9018-G
|
757: E 52 MnMo B
|
|
|
Low hydrogen basic electrode designed for welding in all positions except vertical down. Especially recommended for filler and cover layers of high diameter pipelines.
|
|
|
|
|
Z- 48
|
A5.5 E 9018-M
|
2560-A: E 50 5 Z B 32 H5
|
|
|
Basic coated electrode for welding at very low temperature environment, high strength, and fine grained structural steels with good impact toughness at low temperatures.
|
|
|
|
|
Z- 50
|
A5.5 E 10018-M
|
2560-A: E 50 5 Z B 32 H5
|
|
|
Basic coated electrode for welding at very low temperature environment, high strength, and fine grained structural steels such as navel crafts and submarines. Particularly low diffusible hydrogen content.
|
|
|
|
|
Z- 52
|
A5.5 E 11018-M
|
2560-A: E 50 5 Z B 32 H5
|
|
|
Basic coated electrode for welding high strength steels for military applications
with excellent X-ray quality.
|
|
|
|
|
Z- 53M
|
A5.5 E 12018-M
|
2560-A: E 50 5 Z B 32 H5
|
|
|
Basic coated electrode for welding very high strength steels for military applications.
|
|
|
|
|
Z- 502
|
A5.4 E 502-15
|
1599: E CrMo5 B 32
|
|
|
Basic coated electrode 5% Cr - 0.5% Mo, Service temperature of maximum 600ºC. Welding of Cr-Mo alloys of similar composition Suitable for critical thick joints.
|
|
|
|
|
Z- 505
|
A5.4 E 505-15
|
1599: E CrMo9 B 32
|
|
|
Basic coated 9% Cr- 1% Mo electrode Service temperatures of maximum 650ºC.
|
|
|
|
|
Z- 91
|
A5.5 E 9015-B9
|
3580-A ECrMo 91 B 42 H5
|
|
|
Low hydrogen electrode suitable for welding 9%Cr-1%Mo steels, also known as GRADE 91 designed to provide excellent endurance in creep, fatigue, oxidation and corrosion resistance on high temperatures.
|
|
|
|
